H19 Hex Chisel Bit Integral Rock Drill Rods 19*108mm Stable And
Reliable
H19 Hexagonal Chisel Bit Integral Rock Drill Rods 19mm 108mm Stable
And Reliable
Integral Drill Steel is used by a hand held drill machine in
Underground mining and for small hole drilling, equipped with small
power rock drills, like air leg rock drills, hand held rock drills,
etc. It can reduces the expense of impact energy, improves the
drilling speed and efficiency, also it can be used for drilling
bore hole diameter from 30mm to 41mm usually. Regarding Integral
drill steels, the quality of a steel material and a tungsten
carbide is very important to get good drilling performance.
According to different application, different lengths are available
from 400mm to 5000mm usually.
Shank size:hex19/ 22/ 25mm including plug hole rods
Diameter: 28~41 mm
Length: 400~5000mm
It can reduces the expense of impact energy, improves the drilling
speed and efficiency, also it can be used for drilling bore hole
diameter from 30mm to 41mm usually. Each rods use premium quality
alloy steel and excellent quality tungsten carbide to assure.
Application:
• Widely used in drifting, tunneling, benching, and long hole
drilling
• Blast Hole Drilling
• Africa Copper Mining
• Zambia copper belt province, Africa
• Chile Copper Mining
Mainly Products:
Thread Drill Bits---Diameter: 51mm to 127mm
Thread Type---R22,R25,R28,R32,R38,T38,T45,T51
Face Shape---Plate, Concave, Convex.
Bit Shank & Coupling sleeve---R22,R25,R28,R32,R38,T38,T45,T51
Specifications:
| Shank Style | Length | Head Diameter |
| Mm | foot/inch | Mm | Inch |
| Hex19 × 108mmWe can produce as your request of carbide size,
different length of drill rods. | 400 ~ 4,000 | 1' 4" ~ 13' 1" | 23 ~ 35 | 27/32 ~ 1 3/8 |
| Hex22 × 108mm | 400 ~ 9,600 | 1' 4" ~ 31' 6" | 26 ~ 41 | 1 1/32 ~ 1 39/64 |
| Hex25 × 108mm | 600 ~ 6,400 | 1' 11 5/8" ~ 21' | 33 ~ 45 | 1 19/64 ~ 1 25/32 |
| Hex25 ×159mm | 800 ~ 6,400 | 2' 7" ~ 21' | 35 ~ 42 | 1 3/8 ~ 1 21/32 |
