    DTH Drilling Mission Hammers and Button Bits M40 for Water Well Penetrating

    Ask Lasest Price
    Brand Name : ROSCHEN
    Certification : ISO
    Price : Negotiate
    Supply Ability : 1500 Per month
    Model Number : 3"~12"
    • Product Details
    • Company Profile

    DTH Drilling Mission Hammers and Button Bits M40 for Water Well Penetrating

    Mission Hammers and Button Bits M40 for Water Well Penetrating

    Mission Hammers And Button Bits


    ROSCHEN offers Mission Hammers And Button Bits well designed by our group of designers, these Mission Hammers are sought after amongst our customers. These Mission Hammers And Button Bits sledges are produced utilizing amazing combination steel and hold fast to industry benchmarks. Digger sledges offered by us have higher and reliable entrance rate, have limit and competence to survive high weight and are erosion safe. Our extent is utilized within distinctive applications like water well penetrating, impacting gaps, quarries and common development.


    Size of Hammers 3", 41/2", 43/4", 5", 6", 61/2", Sd8", DHD17", QL20”, NUMA200.

    Mission Hammers and QL40 mission hammers button are made up with standard materials that withstands sledge have been created after broad examination, which guarantees best quality giving sledges longer existence with less need of upkeep, less wear and tear, therefore giving the end client additionally boring meter gauge and ideal execution and more pay being conservative. The "Mission Hammers And Button Bits” are overwhelming obligation and are accessible in sizes extent of 4" to 10" widths.

    The dimensions of mission hammers and button bits are:

    1. DHD340, Mission4, SD4, QL40,
    2. DHD360, QL60, Mission Mega, SD6, Cop64

    3. SD8, DHD380,

    4. SD10

    Mission Hammers And Button Bits are standard products, that confirm to international standards tools and machinery equipment and good quality control methods. ROSCHEN Mission Hammers products are constantly improved with adaptation of the most recent manufacturing technologies and the product features always ensure.

    ROSCHEN DTH Bits Specifications
    Hammer SizeBits diameterShankROSCHEN CODE
    MetricInch
    1"64mm-70mm2 1/2"-2 3/4"BR1ROS 11
    2"70mm-95mm2 3/4"-3 3/4"MACH20/BR2ROS 22
    3"90mm-102mm3 1/2"-4"COP32/COP34/MACH303ROS 32
    M30/DHD3.5/BR3ROS 34
    4"105mm-152mm4 1/8"-6"COP44/DHD340/MACH44ROS 42
    SD4/M40/QL40ROS 44
    5"133mm-165mm5 1/4"-6 1/2"COP54/DHD350R/MACH50ROS 52
    SD5/M50/QL50/BR5ROS 54
    6"152mm-254mm4 1/8"-10"COP64/DHD360/SD6ROS 62
    M60/QL60/Bulroc BR6ROS 64
    8"203mm-330mm8"-13"COP84/DHD380/SD8ROS 82
    QL80/M80/M85ROS 84
    10"254mm-380mm10"-15"SD10ROS 100
    NUMA100
    12"305mm-508mm12"-20"DHD1120/SD12ROS 120
    NUMA120/NUMA125
    Notes: Any special size of DTH bits will be available by requests.
    Metzke, Remet thread is available!

    ROSCHEN DTH Hammers Specifications
    Hammer SizeBit ShankROSCHEN CodeConnection ThreadSuitable bitWorking pressureAir consumption
    2"BR2ROS 11 ROS 22RD50 box¢70-¢90mm0.7-1.75Mpa0.7Mpa4.5m3/min
    1.0Mpa4m3/min
    1.4Mpa5m3/min
    3"DHD3.5ROS 32API 2 3/8" Reg¢90-¢110mm1.0-1.5Mpa1.0Mpa4.5m3/min
    COP32/COP34
    M301.5Mpa9m3/min
    4"DHD340ROS 34API 2 3/8" Reg¢110-¢135mm1.0-2.5Mpa1.0Mpa6m3/min
    COP44
    QL40
    SD41.8Mpa10m3/min
    M402.4Mpa15m3/min
    5"DHD350ROS 52 ROS 54API 2 3/8"Reg/API 3 1/2" Reg¢135-¢155mm1.0-2.5Mpa1.0Mpa9m3/min
    COP54
    QL50
    SD51.8Mpa15m3/min
    M502.4Mpa23m3/min
    6"DHD360ROS 62 ROS 64API 3 1/2" Reg¢155-¢190mm1.0-2.5Mpa1.0Mpa10m3/min
    COP64
    QL60
    SD61.8Mpa20m3/min
    M602.4Mpa28.5m3/min
    8"DHD380ROS 82 ROS 84API 4 1/2" Reg¢195-¢254mm1.0-2.5Mpa1.0Mpa15m3/min
    COP84
    QL801.8Mpa26m3/min
    SD82.4Mpa34m3/min
    M80/M85
    10"SD10ROS 100API 6 5/8" Reg¢254-¢311mm1.0-2.5Mpa1.0Mpa22m3/min
    Numa1001.8Mpa40m3/min
    ROS 1002.4Mpa55m3/min
    12"DHD1120ROS 120API 6 5/8" Reg¢305-¢445mm1.0-2.5Mpa1.0Mpa30m3/min
    SD121.8Mpa56m3/min
    Numa1202.4Mpa78m3/min
    Notes: Any special size of DTH bits will be available by requests.
    Metzke, Remet thread is available!


    Key Features:

    1. Longer Product Life.

    2. Higher and consistent penetration rate.

    3. The capacity and capability to perform hitch-free at higher pressure range.

    4. Reduced number of parts, and compact structure for lower rate of wear&tear.

    5. Avoidance of Back Hammering, Hammer blocking etc.,

    6. Minimum maintenance costs.
