IADC 537 Tungsten Carbide Tricone Roller Drill bits 9 7/8 inch for
Hard Rock Formation Water Well Drilling
Roschen offers a complete line of tricone drill bits. Tricone bits
are available in new and used (re-tip and re-run) steel tooth and
tungsten carbide insert, in sizes from 2 1/2 to 36, for use in all
formations, with any bearing/seal type, and with a wide range of
additional custom features.
New Tricone Drill Bits
Roschen offers new steel tooth and tungsten carbide insert (tci)
tricone bits in sizes from 2 1/2" – 36", with open or sealed
bearings, regular or jet circulation, and a wide range of
additional custom features for ideal performance in any formation.
Tricone bits can be customized to optimize penetration rates and
bit life in particular formations and under specific operating
weights and rotation speeds.
Tricone rotary bits are sometimes a good alternative to a DTH
hammer. Available in TCI (carbide buttons) and mill tooth
configurations.
We carry a large inventory of rerun bits and can also supply new
bits. TCI bits are available for Medium Soft, Medium Hard, and Hard
formations. Please call us to check stock.
Remember, when drilling with Tricone Bits you need to maintain
proper down pressure to prevent premature bearing failure
For examples:
Click here to view IADC codes for additional tricone bit ordering
guidelines.
IADC Codes - Tricone Rock Bits
IADC Codes are designed to make it easier for drillers to describe
what kind of rock bit they are looking for to the supplier.
The first three digits classify the bit according to the formation
it is designed to drill and the bearing/seal design used.
Bit Type and Hardness of Formation to be Drilled
First Digit:
1, 2, and 3 steel tooth bits (from softest to hardest).
4, 5, 6, 7, and 8 tungsten carbide insert bits (from softest to
hardest).
Formation SubCategory
Second Digit:
from softest (1) to hardest (9).
Bit Feature
Third Digit:
1. Open Bearing
2. Open Bearing, Air Cooled
3. Open Bearing with Gauge Protection
4. Sealed Roller Bearing
5. Sealed Roller Bearing wih Gauge Protection
6. Sealed Journal Roller Bearing
7. Sealed Journal Roller Bearing with Gauge Protection.
Contact a Roschen representative for additional details about our
complete line of new tricone drill bit product offerings.
Re-Tip Steel Tooth Tricone Drill Bits
Re-tip steel tooth tricone bits are gently used bits that usually
come from the oil fields. They are refurbished for use in
non-oilfield rotary applications, such as water wells, HDD, and
construction type drilling. These bits offer significant cost
savings over new bits. Roschen offers a wide range of premium, oil
field quality re-tip steel tooth bits in sizes ranging from 2 1/2"
to 36". Re-tip bits are available for use in soft, medium, and hard
formations.
Contact a Roschen representative for additional details about our
complete line of re-tip steel tooth tricone drill bit product
offerings.
Re-Run Carbide Insert Tricone Drill Bits
Re-run carbide insert bits are used bits that have been re-worked,
cleaned, and often times painted. Re-runs offer significant cost
savings over new carbide insert bits. Roschen offers a variety of
re-run carbide bits in sizes ranging from 2 1/2" to 36". All
re-runs are premium quality and available for use in soft, medium,
and hard formations.
Contact a Roschen representative for additional details about our
complete line of re-run carbide insert tricone drill bit product
offerings
| TRICONE DRILL BITS - STANDARD CONNECTION SIZES * |
| SIZE | STANDARD PIN CONNECTION |
| 2 1/2" to 2 3/4" inclusive | A - AW Rod |
| 2 7/8" to 3 3/8" inclusive | N4 Rod |
| 3 1/2" to 4 1/2" inclusive | 2 3/8" API |
| 4 5/8" to 5" inclusive | 2 7/8" API |
| 5 1/8" to 7 3/8" inclusive | 3 1/2" API |
| 7 1/2" to 9 3/8" inclusive | 4 1/2" API |
| 9 1/2" to 14 3/8" inclusive | 6 5/8" API |
| 14 1/2" to 18 1/2" inclusive | 6 5/8" API or 7 5/8" API |
| 18 5/8" to 26" inclusive | 7 5/8" API or 8 5/8" API |
| 27" and larger | 8 5/8" API |
| *Tricone bits are available with alternative connection sizes on
request. |
