Compact Diesel Engine Drilling Mud Pump 132KW with Electric Motor
Model: RS-1000 Mud pump
Horizontal Triplex Mud pump
Horizontal triplex single acting reciprocation piston pump
Horizontal Triplex Mud Pump BW1000 Single Acting Reciprocation with
Diesel Engine
Horizontal Triplex Mud Pump BW1000 Single Acting Reciprocation with
Diesel Engine , Deutz Engine, Cummins Engine
RS-1000 Mud Pump Description:
RS-1000/12 mud pump is a horizontal, triplex, single acting
reciprocation piston pump. It can be driven by diesel engine,
electric motor or hydraulic motor, and it is reliable and agile and
simple for operation. It can be controlled at close range or
long-distance. It also has many other merits such as compact
structure, running smoothly, large-scale variable rates of flow,
high output pressures, longer service life of the wearing parts and
steady performance, good intensity and rigidity, plentiful standard
parts and interchangeable parts and so on.
The pump has 5 shifts to give birth to 5 different discharge and
pressure, and its parameters are reasonable to meet different
construction process demands. It is mainly used to match horizontal
directional pipe laying drilling machine that is 100t or so, also
it can meet the needs of construction for water well and earth
heat, superficial layer oil drilling and mine drainage.
Features:
1. Compact structure, light weight, small volume, beautiful
appearance, is driven by a hydraulic motor, motor, diesel engine
2. The design on the use of new ideas, new structure, new
materials, new technology;
3. Horizontal pump to improve standardization, seriation,
generalization,crankshaft, connecting rod body, the cross head, the
pump head and some other components related to serialization and
the universal, the other components of the reduced species
4. Loss of long life, high reliability
Technical Parameters:
Model | RS-1000, RS-1000/12 Mud Pump |
Type | Horizontal, triplex, single acting reciprocation piston pump |
Cylinder bore(mm) | φ135 |
Stroke(mm) | 150 |
Pump speed(min-1) | 158 | 130 | 91 | 59 | 37 |
Discharge(l/min) | 1000 | 835 | 580 | 380 | 235 |
Pressure(MPa) | 6 | 7 | 10 | 12 | 12 |
Driving Power(Kw) | 132KW |
Suction Pipe Dia.(mm) | φ127 |
Discharge Pipe Dia.(mm) | φ76 |
Weight (Kg) | 3500 |
