Secoroc RC 50 hammer
Secoroc RC 50 hammer 5 inch, Reverse Circulation RC140 button bits
with 4 1/2" Remet Box
Roschen Reverse Circulation Hammer can instead of Atlas Copco
Secoroc's reverse circulation hammers
Roschen's reverse circulation hammers are specifically designed for
all kind of exploration drilling (deep hole and pit grade control
applications).
Whether you are exploring potential sites or working an existing
mine, the Secoroc RC hammer will assure of high performance,
exceptional reliability and dependable support.
| RC 50 hammer |
| Description | Product No. | Product code | Thread connection | Outside diameter | Rec. hole size | Shank style | Working pressure | Length without bit, shoulder to shoulder | Weight without bit |
| mm | inch | mm | inch | bar | psi | mm | inch | kg | lbs |
| 5" |
| RC 50 STD | 52292273 | 9705-52-67-00 | 4 1/2" Remet Box | 130 | 5.13 | 136-165 | 5 3/8 - 6 ½ | RC 50 | 10-35 | 145-500 | 1152 | 45.4 | 72 | 158 |
| RC 50 bit assortment |
| Diameter | Product No. | Product code | No. × Button diameter, mm (inch) | Gauge/ Button
angle° | Flushing
holes | Weight
approx |
| mm | inch | Outer | Inner | Front | Outer | Inner | kg | lbs |
| DROP CENTER, EXTRA FLUSHING |
| 136 | 5 3/8 | 90516434 | 10E-5136-97-7217,08-20 | 8 x 16 (5/8) | 4 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 18,6 | 41 |
| 140 | 5 1/2 | 90516432 | 10E-5140-97-7217,08-20 | 8 x 16 (5/8) | 4 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 18,9 | 41 |
| 143 | 5 5/8 | 90516472 | 10E-5143-97-7217,08-20 | 8 x 16 (5/8) | 4 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 18,9 | 41 |
| 146 | 5 3/4 | 90516433 | 10E-5146-97-7217,08-20 | 8 x 16 (5/8) | 4 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 19,3 | 43 |
| 152 | 6 | 90516558 | 10E-5152-97-7217,08-20 | 8 x 16 (5/8) | 4 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 19,9 | 43 |
| 165 | 6 1/2 | 90516435 | 10E-5165-97-7217,08-20 | 8 x 16 (5/8) | 6 x 12,7 (1/2) | 4 x 16 (5/8) | 35 | | No | 20,5 | 44 |
