    MACH 60 DTH Hammer for Rock Blast Drilling , Water Well Drilling

    Ask Lasest Price
    Brand Name : ROSCHEN
    Model Number : MACH 60
    Certification : ISO
    Price : Negotiate
    Supply Ability : 10000 sets
    • Product Details
    • Company Profile

    MACH 60 DTH Hammer for Rock Blast Drilling , Water Well Drilling

    DTH RC Drilling Hammers, Reverse Circulation Water Well Drilling Hammer





    MACH RANGE

    This is a proven hammer that has been around for over 30 years and is designed for all kinds of drilling conditions but excels in overburden drilling due to the high frequency with less blow energy for drilling through unstable ground conditions. This hammer can drill smaller diameters than the standard range. This range of hammer is ideal for civil engineering.

    DOMINATOR RANGE

    The Dominator is a higher performance hammer than the Mach Range ideally suitable for medium to higher air pressures in blast-hole applications. This design is simple with fewer components, which makes servicing and on-site maintenance easy. With a range of heavy duty models on offer this extends the life of the hammer considerably.


    SUPER DOMINATOR RANGE

    The Super Dominator is the latest hammer in the range, specially designed for working at extreme high working pressures up to 500 psi with high penetration rates ideal for blast-hole and water well applications. The Super Dominator Range has a simple design with no make-up required. This hammer has an external non-return-valve for easy inspection and service and is available with a 12 spline drive system to reduce shank breakage.

    GW RANGE

    The new GW series of DTH hammers from Roschen Rock Tools offer breakthrough performance in challenging Geothermal and Water well applications. The robust non ported piston design dramatically improves both the piston and internal component life when drilling under a column of water. A built in choke facility allows the driller to adjust the volume of air through the hammer to optimize cuttings evacuation. GW500 and GW600 hammers are fitted with a reversible cylinder to maximize operating life and are suitable for operation at air pressures up to 30 bar (435 psi).



    ROSCHEN DTH Hammers Specifications
    Hammer SizeBit ShankROSCHEN CodeConnection ThreadSuitable bitWorking pressureAir consumption
    2"BR2ROS 11 ROS 22RD50 box¢70-¢90mm0.7-1.75Mpa0.7Mpa4.5m3/min
    1.0Mpa4m3/min
    1.4Mpa5m3/min
    3"DHD3.5ROS 32API 2 3/8" Reg¢90-¢110mm1.0-1.5Mpa1.0Mpa4.5m3/min
    COP32/COP34
    M301.5Mpa9m3/min
    4"DHD340ROS 34API 2 3/8" Reg¢110-¢135mm1.0-2.5Mpa1.0Mpa6m3/min
    COP44
    QL40
    SD41.8Mpa10m3/min
    M402.4Mpa15m3/min
    5"DHD350ROS 52 ROS 54API 2 3/8"Reg/API 3 1/2" Reg¢135-¢155mm1.0-2.5Mpa1.0Mpa9m3/min
    COP54
    QL50
    SD51.8Mpa15m3/min
    M502.4Mpa23m3/min
    6"DHD360ROS 62 ROS 64API 3 1/2" Reg¢155-¢190mm1.0-2.5Mpa1.0Mpa10m3/min
    COP64
    QL60
    SD61.8Mpa20m3/min
    M602.4Mpa28.5m3/min
    8"DHD380ROS 82 ROS 84API 4 1/2" Reg¢195-¢254mm1.0-2.5Mpa1.0Mpa15m3/min
    COP84
    QL801.8Mpa26m3/min
    SD82.4Mpa34m3/min
    M80/M85
    10"SD10ROS 100API 6 5/8" Reg¢254-¢311mm1.0-2.5Mpa1.0Mpa22m3/min
    Numa1001.8Mpa40m3/min
    ROS 1002.4Mpa55m3/min
    12"DHD1120ROS 120API 6 5/8" Reg¢305-¢445mm1.0-2.5Mpa1.0Mpa30m3/min
    SD121.8Mpa56m3/min
    Numa1202.4Mpa78m3/min
    Notes: Any special size of DTH bits will be available by requests.
    Metzke, Remet thread is available!



    Application





    MACH 60 DTH Hammer for Rock Blast Drilling , Water Well Drilling

    AVAILABLE SHANKS:

    Dominator 100
    DHD 3.5
    Mach 50
    Mach 60
    Mach 80
    SD 10
    QL 120
    Mach 20
    SD 450
    SD 5
    SD 6
    SD 8
    DHD 112

    Mach 303
    Mach 44
    DHD 350R
    DHD 360
    DHD 380
    DHD 112S

    MD 3.5
    DHD 340A
    QL 50
    QL 60
    QL 80
    SD 12


    DTH Button Bits Mission 40 140mm Down The Hole In Australia Mining For Well Drilling


    DTH Button Bits
    Diameter: 57mm-660mm
    Application: Well drilling, Ore mining, Coal mining
    Shank of Bit: DHD,COP,Mission,SD,QL,TD,BR
    Basic Bit Designs: Convex, Flat front, Speed Bit, Concave, Rocket Bit
