Forged End HDD Drill Rods 6 5/8 Inch , custom Drill Bit Extension Bar

HDD Drill Rods 6 5/8inch

ROSCHEN carries a number of popular sizes in Ditch Witch drill forged-end friction welded pipe. Connect with our horizontal drilling experts to determine the proper part specifications for your order. Best of all, many of our Ditch Witch drill pipe options come with an unconditional guarantee on the inertia weld, irrespective of operating conditions.

ROSCHEN offers an extensive selection of horizontal directional drill rods that are compatible with Vermeer and Ditch Witch equipment. Only the highest quality materials are used in our rods and our cutting-edge manufacturing process is designed to ensure superior HDD drill pipe strength and durability. Get in touch with one of our World HDD drilling specialists to learn more about the type of HDD drill pipe that you need for your horizontal drilling project.

Normal Size	Normal Weight	Grade	Upset	Wall Thickness	ID	Torsional Strength	Tensile Strength	Burst Pressure	Collapase Pressure	Connection	OD	ID	Pin Tong Space	Box Tong Space	Make-up Torque	Torsional Strength	Tensile Strenght	Torsional ratio	Adjusted Weight	Fluid Capacity	Fluid Displacement
in	lbs/ft			in	in	ft-lbs	lbs	psi	psi		in	in	in	in	ft-lbs	ft-lbs	lbs		lbs/ft	US gal/ft	US gal/ft
5	19.50	S-135	IEU	0.362	4.276	74100	712070	17105	15672	NC-50	6 5/8	2 3/4	9	12	38036	63406	1551706	0.86	24.09	0.7	0.37
5	19.50	S-135	IEU	0.362	4.276	74100	712070	17105	15672	NC-50 DS	6 5/8	3 1/4	9	12	43320	72200	1250000	97	23.19	0.71	0.35
5	25.60	S-135	IEU	0.500	4	94062	954259	23625	24300	NC-51 DS	6 5/8	2 3/4	9	12	55600	92600	1532800	0.98	24.04	0.7	0.37
5 1/2	21.90	S-135	IEU	0.361	4.778	91278	786809	15507	12679	5 1/2 FH DS	7 1/4	3 1/2	10	12	68270	113485	1754166	1.24	26.93	0.88	0.41
5 1/2	24.70	S-135	IEU	0.415	4.67	101834	894999	17826	17023	5 1/2 FH DS	7 1/4	3 1/2	10	12	68270	113485	1754166	1.11	29.66	0.85	0.45
5 1/2	24.70	S-135	IEU	0.415	4.67	101834	894999	17826	17023	5 1/2 FH	7 1/2	3	10	12	52059	87341	1925536	0.86	30.88	0.83	0.47
6 5/8	27.70	S-135	IEU	0.362	5.901	137331	961556	12909	7813	6 5/8 FH	8 1/2	4 1/4	10	13	65012	109227	2102260	0.8	34.17	1.34	0.53
6 5/8	27.70	S-135	IEU	0.362	5.901	137331	961556	12909	7813	6 5/8 FH DS	8 1/2	4 1/4	10	13	101685	169475	2277448	1.23	34.17	1.34	0.53
6 5/8	27.70	S-135	IEU	0.362	5.901	137331	961556	12909	7813	6 5/8 FH DS	8	4 3/4	10	13	74465	124110	1817990	0.9	31.82	1.36	0.48
6 5/8	27.70	S-135	IEU	0.362	5.901	137331	961556	12909	7813	5 1/2 FH DS	7 1/2	3 1/2	12	14	79000	131723	1754166	0.96	31.33	1.32	0.47
7 5/8	33.70	S-135	IEU	0.430	6.765	214941	1312148	14465	8584	6 5/8 FH DS	8 1/2	4 1/4	13	15	102520	170870	2277448	0.79	44.91	1.72	0.67
7 5/8	33.70	S-135	IEU	0.430	6.765	214941	1312148	14465	8584	6 5/8 FH DS	8 1/2	4 3/4	13	15	75662	126104	1817990	0.59	43.92	1.75	0.65
7 5/8	39.00	S-135	IEU	0.500	6.625	243035	1510920	15492	12651	6 5/8 FH DS	8 1/2	4 1/4	13	15	102520	170870	2277448	0.7	49.91	1.66	0.74
7 5/8	39.00	S-135	IEU	0.500	6.625	243035	1510920	15492	12651	6 5/8 FH DS	8 3/4	4	13	15	114800	191410	2488032	0.79	51.31	1.65	0.77
8 5/8	44.00	S-135	IEU	0.500	7.625	318253	1722967	13696	14745	JSH 7 1/8 FH DS *1	9 1/2	4	16	19	157900	263200	3056200	0.78	59.71	2.18	0.95
8 5/8	44.00	S-135	IEU	0.500	7.625	318253	1722967	13696	14745	JSH 70 DS *2	9	4	16	19	131000	218300	2735700	0.69	57.16	2.18	0.87
*1 tool joint connection type recommended by JSH
*2 tool joint connection type recommended by the customer

High-Quality Drill Rods & Pipes, Knowledgeable Service

ROSCHEN focus on manufacturing high-quality drill rods and at the best quality and price. Our respected experts are here to ensure that you get the drill pipe you need to fit your equipment with the right specifications. No downtime, just the right pipe to keep your horizontal directional drilling project on schedule.

Our high-quality products are manufactured to conquer even the most demanding drilling projects. Servicing all major small to mid-size directional drilling rigs, ROSCHEN is here to make sure you have the right rod for your HDD project.

Buying the Right Drill Rods

ROSCHEN understand that having the correct information to make an informed decision when buying a drill rod is of the essence. We formed Drill Rod teams to provide our customers with the information needed to choose the right drill rod for your application.

From buying the right drill rods to promoting good practices to extend the life of your drill and common drill rod manufacturing methods, ROSCHEN is here to make sure you have the not only the right rod for your HDD project but the information to get the most out of your investment.
