    HQ NQ PQ BQ Wireline Drill Rods Quenching Heat Treatment High Stregnth Drill Rod For Damond Core Drilling

    Ask Lasest Price
    Brand Name : ROSCHEN
    Model Number : NWJ
    Certification : ISO
    Price : Negotiate
    Supply Ability : 10000000 pcs
    • Product Details
    • Company Profile

    HQ NQ PQ BQ Wireline Drill Rods Quenching Heat Treatment High Stregnth Drill Rod For Damond Core Drilling

    HQ NQ PQ BQ Wireline Drill Rods Quenching Heat Treatment High Stregnth Drill Rod For Damond Core Drilling

    Oil Hardened Drill Rod Description


    This drill rod is the equipment that connects the drilling tools and drilling bits, and it is mainly used to transmit power. It mainly consists of a tubing body and two thread ends.


    Overall capacity:

    1. A variety of hot-rolled seamless pipes of large diameter and small-diameter pipes complete range of sizes, from the outside diameter of 21.3mm to 1500mm, wall thickness from the 2mm to 250mm.
    2. A comprehensive selection of materials available in carbon steel, alloy steel and other special materials in accordance with customer requirements.
    3. Strong R & D base Top scientists and experts in research centers owned by the Group to develop for the future.

    Oil Hardened Drill Rod Specifications:

    1. High Penetration Rate
    2. Longer lifetime
    3. Lower Using Cost
    4. Excellent cemented carbide
    5. AW, BW, NW, HW, PW, BWL, HWL, NWL, PWL
    6. High Cost-effective

    Size Available:

    Wireline Series: B, N, H, P
    "WJ" Design: AWJ, BWJ, NWJ, KWJ, HWJ
    "W" Design: RW, EW, AW, BW, NW, HW
    Metric Series: 33, 42, 50, 56, 66, 76, 86, 89, 101

    "W" Design: RW, EW, AW, BW, NW, HW, PW, SW, UW, ZW/HWT, PWT
    Metric Series: 46, 56, 66, 76, 86, 101, 116, 131, 146
    "X" Design: RX, EX, AX, BX, NX, HX, PX, SX, UX, ZX
    We also can produce various sizes of casing tubes.

    All worldwide standard Sizes will be available.

    NoSizeOD(mm)ID(mm)Thread typeWeight (kg/m)
    1Φ7373.565.5DCDMA7
    2Φ898981DCDMA9.4
    3Φ108108.599.5DCDMA12
    4Φ127127.5118DCDMA14
    4Φ146146.5137DCDMA18
    6Φ168168154DCDMA28
    7Φ178178164DCDMA30
    8Φ194194181DCDMA33

    Technical parameters:
    DescriptionODIDWeight(kg)
    AW 3.0m(10') CASING57.10(mm)48.40(mm)17 (kg/3m)
    AW 1.5m(5') CASING2.25(in)1.91(in)38(Ib/10ft
    BW 3.0m(10') CASING73.00(mm)60.30(mm)31.30(kg/3m)
    BW 1.5m(5') CASING2.88 (in)2.38(in)70 ( Ib/10ft)
    NW 3.0m(10') CASING88.90(mm) 3.5(in)76.20(mm) 3.00 (in)38.4(kg/3m) 86(lb/10ft)
    NW 1.5m(5') CASING
    NW 1.0m(2') CASING
    HW 3.0m(10') CASING114.30(mm) 4.50(in)101.60(mm) 4.00 (in)52.20(kg/3m) 17.00(lb/10ft)
    HW 1.5m(5') CASING
    HW 1.0m(2') CASING
    HWT 3.0m(10') CASING114.30(mm) 4.50(in)101.60(mm) 4.00 (in)52.20(kg/3m) 17.00(lb/10ft)
    HWT 1.5m(5') CASING
    HWT 1.0m(2') CASING
    PW 3.0m(10') CASING139.70(mm) 5.50(in)127.00(mm) 5.00(in)64.30(kg/3m)144.00(lb/10ft)
    PW 1.5m(5') CASING
    PW 1.0m (2') CASING

    Pictures
