Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Wired Drill Pipe Description:
Drill pipes that are used in applications such as DTH/ DTHR/ DR
basically comprise of a steel pipe with a pin at one end and a box
on the other. The job of the drill pipe is to transmit rotational
torque and thrust from the drill rig rotary head to down hole
drilling tools.
According to different application, different diameters of drill
tubes are needed, basically, smaller DTH hammers need smaller DTH
drill tubes, vice versa. Usually we are offering 50mm, 60mm, 76mm,
89mm, 95mm, 102mm, 114mm 127mm, 140mm, 159mm etc.
Usually the threads are standard API connections, like 2 3/8" API
REG thread, 3 1/2" API REG thread or API IF thread, etc.
According to customers request, from1000mmto6000mmlength of pipe
are available.
Wired Drill Pipe Features:
1. Thread oil should be used when screwing the drill rod and hammer
knocking should be prohibited.
2. The drill rod stand should have buffer materials, like wood,
rubber, and more. The contact between the threaded ends and iron
tools should be forbidden.
3. During the relocation of drill rod, the thread protector should
be screwed on the threaded parts so as to protect it from damages.
Wired Drill Pipe Technical Parameters:
| J-Series Drill Rod Assembly | Outside Diameter | Threads | Assembly Length | Assembly Weight | Assembly Part Number |
| Per Inch |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 1-Foot (305mm) | 3-Pounds (1.4 kg) | 27014 |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 2-Foot (610mm) | 6-Pounds (2.7 kg) | 27015 |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 3-Foot (914mm) | 11-Pounds (5 kg) | 27016 |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 4-Foot (1.2m) | 16-Pounds (7.3 kg) | 27136 |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 5-Foot (1.5m) | 20-Pounds (9.1 kg) | 27017 |
| AWJ | 1-3/4-inch (35mm) | 5-TPI | 10-Foot (3.1m) | 32-Pounds (14.5 kg) | 27018 |
| NWJ | 2-5/8-inch (67mm) | 5-TPI | 1-Foot (305mm) | 7-Pounds (3.2 kg) | 27009 |
| NWJ | 2-5/8-inch (67mm) | 5-TPI | 2-Foot (610mm) | 15-Pounds (6.8 kg) | 27010 |
| NWJ | 2-5/8-inch (67mm) | 5-TPI | 3-Foot (914mm) | 18-Pounds (8.2 kg) | 27011 |
| NWJ | 2-5/8-inch (67mm) | 5-TPI | 5-Foot (1.5m) | 30-Pounds (13.6 kg) | 27012 |
| NWJ | 2-5/8-inch (67mm) | 5-TPI | 10-Foot (3.1m) | 60-Pounds (27.2 kg) | 27013 |
Wireline Series Drill Rods:
| Specifications of Drill Rods |
| Size | OD (mm) | ID (mm) |
| WLA | 44.7 | 37.3 |
| WLB | 55.7 | 46.1 |
| WLN | 70.0 | 60.2 |
| WLH | 89.0 | 78.0 |
| WLP(PHD) | 114.5 | 101.5 |
| AW/AWJ/AWY | 43.7 | 30.7 |
| BW/BWJ/BWY | 54.0 | 38.0 |
| NW/NWY | 66.8 | 51.0 |
| HW | 89.0 | 71.0 |
| Φ42 | 42.0 | 30.0 |
| Φ50 | 50.0 | 37.0 |
| Φ60 | 60.0 | 48.0 |
| Φ70 | 73.0 | 54.6 |
| Φ90 | 89.0 | 69.0 |
| S75 | 71.0 | 61.0 |
AW, BW, NW, AWJ, BWJ, NWJ, N3, N4 Series:
| Size | O.D. | Rod Body I.D. | Weight | Threads per Inch | Volume |
| in | mm | in | mm | lbs/10ft | kg/3m | gal/100ft | L/100m |
| AW | 1.75 | 44.5 | 1.25 | 31.8 | 44 | 19.6 | 3 | 6 | 75 |
| BW | 2.13 | 54 | 1.75 | 44.5 | 40 | 18.2 | 3 | 12.5 | 155 |
| NW | 2.63 | 66.7 | 2.25 | 57.1 | 51 | 23.3 | 3 | 20.7 | 257 |
| AWJ | 1.75 | 44.5 | 1.37 | 34.9 | 33 | 14.7 | 5 | 7.2 | 90 |
| BWJ | 2.13 | 54 | 1.75 | 44.5 | 40 | 18.2 | 5 | 11.8 | 146 |
| NWJ | 2.63 | 66.7 | 2.25 | 57.1 | 55 | 24.6 | 4 | 19.6 | 244 |
| N3 | 2.38 | 60.45 | 1.13 | 28.7 | N/A | N/A | 3 | 80.1 | 36.33 |
| N4 | 2.13 | 54.1 | 1 | 25.4 | N/A | N/A | 4 | 80.1 | 36.33 |
| No | Size | Drill rod | Thread type | Raw material |
| OD mm | ID mm |
| 1 | AWJ | 44.5 | 34.1 | DCDMA Standard | 45MnMoB R780 |
| AWY |
| 2 | BWJ | 54 | 44.5 |
| BWY |
| 3 | NWY | 67 | 57 |
| 4 | HW | 89 | 77.8 |
| 5 | Φ42 | 42 | 32 | China GB standard | R780 |
| 6 | Φ50 | 50 | 39 | R780 |
| 7 | Φ60 | 60 | 48 | R780 |
Wired Drill Pipe Pictures
