Reverse Circulation Drill Pipe 4 1/2'' Remet Thread For RC Hammer
Bit
Selecting the right drill pipe
Drill pipes that are used in applications such as DTH/ DTHR/ DR
basically comprise of a steel pipe with a pin at one end and a box
on the other. The job of the drill pipe is to transmit rotational
torque and thrust from the drill rig rotary head to down hole
drilling tools.
According to different application, different diameters of drill
tubes are needed, basically, smaller DTH hammers need smaller DTH
drill tubes, vice versa. Usually we are offering 50mm, 60mm, 76mm,
89mm, 95mm, 102mm, 114mm, 127mm, 140mm .
The Roschen service guarantee
. Service that gives you the right equipment, the first time, and
quickly.
. Well engineered, quality equipment designed for rugged drilling
situations.
. Knowledgeable product support to help you increase productivity.
. Rapid and accessible sales support that makes ordering quick and
easy.
You can be sure that at Roschen's, we have a clear understanding of
the problems involved in maintaining reverse circulation drill
rig’s at full production in remote and rugged sites. Our year’s of
experience in the industry ensure that you get exactly the products
and service you need to keep your RC drilling rigs at their peak
wherever you are drilling.
| Sizes | 3", 3 ½", 4", 4 ½", 75mm and 78mm |
| Thread Types | Remet, Metzke, RRE, Westrod, LW, TS and other threads |
| REVERSE CIRCULATION DRILL ROD SPECIFICATIONS |
| Thread Type | Remet | Remet | Remet | Metzke | Metzke | Matrix | Matrix |
| Rod O.D. | 3 1/2" | 4" | 4 1/2" | 4" | 4 1/2" | 4" | 4 1/2" |
| Outer Tube O.D. | 88.9mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm |
| Outer Tube I.D. | 81.8mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm |
| Outer Tube W.T. | 5.3mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm |
| Inner Tube O.D. | 38.1mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm |
| Inner Tube I.D. | 32.6mm | 45.3mm | 58mm | 45.3mm | 58mm | 45.3mm | 58mm |
| Inner Tube W.T. | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm |
| Spanner Flat | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm |
| Weight 3.0m | 75kg. | 75kg. | 95kg. | 75kg. | 95kg. | 75kg. | 95kg. |
| Weight 6.0m | 120kg. | 150kg. | 168kg. | 150kg. | 168kg. | 150kg. | 168kg. |
